oboi reloaded, 128b,Sam Coupe

coma128b, Sam Coupe



RGB isometric cube



wr128b(ZX128), 48K improved for 48K v2


reuleaux(2nd @party 2021)

Немного трюков из поуета, ибо впадлу листать:

[PALETTE CODE REMOVED - ax = cx = 0 after it]

_mainloop: _loop: db 0xbb ; mov bx, 320

_320i: dw 320 ;

pusha needed due to some other things happening ;)


mov ax, di

div bx ; dx = x & ax = y

db 0x81, 0xea ; sub dx, 160

_160i: dw 160

db 0x2d ; sub ax, 100

_100i: dw 100


mov al,13h ;MCGA mode (320x200x256).
int 10h ;Video interrupt request.
les bp,[bx] ;Sweet little trick that loads 0a000h
;(the beginning of the VGA video memory)
;into es (instead of, say, "push word ;0a000h" and then "pop es").

; 19 bytes sine table approx from 0 to 2*Pi : 255 values amplitude=53 [-26;0;+26]


mov bx,ax ; al=bl=x

imul bl ; ax=x*x

mov al,ah ; ax=x*x*256+x%256

imul bl ; ax=x*(x*x*256+x%256)

mov al,ah ; ax=(x*(x*x*256+x%256))*256+(x*(x*x*256+x%256))%256

shr bx,2 ; bx=x/4

add al,13 ; ax=13+(x*(x*x*256+x%256))*256+(x*(x*x*256+x%256))%256

sub ax,bx ; ax=-x/4+100+(x*(x*x*256+x%256))*256+(x*(x*x*256+x%256))%256

db 0d4h,64 ; ax=(-x/4+100+(x*(x*x*256+x%256))*256+(x*(x*x*256+x%256))%256)%64


;9 bytes parabola

_sin:          ; sin(x)=(x*4/pi)-x*x*(4/pi*pi) if x>0 from from http://www.coranac.com/2009/07/sines/ in deg : sin(x)=(10*x-x*x)/6000*scale
               ; sin(x)=(x*4/pi)+x*x*(4/pi*pi) if x=<0
mov bx,ax      ; al=bl=x
mul al         ; ax=x*x
xchg ax,bx     ; ax=x bx=x*x
aad            ; ax=10*x  (2 bytes smaller than mov dl,10 + mul dl)
sub ax,bx      ; ax=10*x-x*x if x>0 else branch/replace by add ax,bx or use absolute value trick
mov al,ah
ret            ; ah=6000*scale, using scale=23,4375 ah=256*al


Pseudo Random number generator    ASM/8086


Here is a small pseudo random generator. I found it on Andrew Griffinis homepage, but I seem to have misslaid his e-mail and homepage address.

; pseudo random number generator
; input:
;   bp = seed (!=0)
; output:
;   ax = random word
; destroys:
;   bp
;   flags

    mov     al,16
r_loop: rol     bp,1
    jnc     r_skip
    xor     bp,0ah

r_skip: dec     al
    jne     r_loop
        mov     ax,bp
One improvement that can be done is to replace store BP someway so you can reuse it later in the random routine.
Max McGuire has submitted a new version (note that in order for this version to run on a 286 and below, FS has to be replaced with another segment register):

I'm submitting to you an alternative pseudo random generator that I found in the source for the intro Chaos by Consub of CSB. Here's his original code:

        mov     ax,fs
        mov     bx,13
        mul     bx
        xchg    ah,al
        mov     fs,ax
I kept the same basic idea, but optimized (at least I think I optimized) this code for speed by making a few changes (I also changed the seed from fs to dx):
        mov     bx,dx
        shl     dx,2
        add     dx,bx
        xchg    dl,dh
I don't know if this algorithm generates random numbers that are uniformly distributed between 0 and 65535


ожыдание вывода на экран:

verical retrace check:
mov dx, 3dah

in al, dx
test al, 8
jz @wait1

in al, dx
test al, 8
jnz @wait2

проверка нажатия Esc:

in al, 0x60
dec al
jnz short _mainloop


SALC - Set AL on Carry ASM/8086

This small gem presents an undocumented opcode available on all Intel CPUs. The instruction mnemonic is called SALC and sets AL to match the carry flag, ie if the Carry is set, AL will be set to FF, else zero. The instruction macro looks like this:

; salc - set al to carry (undocumented opcode)
; input:
; none
; output:
; al = 0FFh * CF
; destroys:
; nothing
 db 0d6h

It does not affect any flags. It was first documented officially when Intel released the Pentium Pro processor. It is officially named SALC.



_palette: mov dx, 0x3c9

times 3 out dx, al

inc ax

jnz short _palette

This is what I currently use - inspired by the palette code of some other 256b/128b intros (one of them is spongy - not sure what the other intro with the "ignore setting the index" trick was and another one brought the salc trick for setting ax to zero). Not sure whether that's a good idea or not ;)


Nice rotation code from baze/3SC.



fld st2

fmul st0, st1

fld st4

fmul st0, st3

fsubp st1, st0

fxch st3

fmulp st2, st0

fmulp st3, st0

faddp st2, st0

;Input st0=A st1=X st2=Y st3=Z Output st0=(cos(A)*X - sin(A)*Y) st1=(cos(A)*Y + sin(A)*X) st2=Z


int 2jkjkghghk0h


интро, написанное из-за того, что вахрушка Gargaj влепил двухдневный бан из-за пиздежа чмыря Димочки Быстрова.

сокращенная до мизера программа:/hilb156.rar
Работа выставленная на CSS CGC 2013
интро, полученное в результате одного глюка:/Mistake256b.rar
просто от нехуй делать/ca00.rar
осилен0 косноязычное описание "Клеточная Вселенная" Девида Гриффита/ca01.rar
нашел картинку, затем на web.archive сырки/hex.rar
Немного работ с Outline:
